Total stations

Specification:- Angle display: 360° ’ ’’, 360° decimal, 400 gon, 6400 mil, V% Operating time: typ. 5 – 8 h Circular Level Dust / water (IEC 60529): IP54 Data storage Battery (GEB221): 0.2 kg Display: 1/4 VGA (320*240 pixels), graphic LCD, colour, illumination, …

Specification:-

• Angle display: 360° ’ ’’, 360° decimal, 400 gon, 6400 mil, V% Operating time: typ. 5 – 8 h
• Circular Level Dust / water (IEC 60529): IP54
• Data storage Battery (GEB221): 0.2 kg
• Display: 1/4 VGA (320*240 pixels), graphic LCD, colour, illumination, Type: Lithium-Ion touch screen Voltage: 7.4
• Distance display: meter, int. ft., int. ft/inch, US ft, US ft/inch Weights Position: face I standard / face II optional Total station: 4.8 – 5.5 kg
• Environmental specifications
• Focusing range: 1.7 m to infinity Number of drives: 1 horizontal / 1 vertical
• Horizontal Range 5km or better, Angular Accuracy 2 second, Telescope Laser plummet, Magnification: 30 x Centering accuracy: 1.5 mm at 1.5m,Free objective aperture: 40mm Laser dot diameter: 2.5 mm at 1.5mField of view: 1°30’ (1.66 gon) / 2.7 m at 100 m Endless drives
• Interfaces: RS232, Bluetooth® Wireless-Technology, Storage
• Internal memory: 256MB, Tribrach (GDF121): 0.8 kg
• Keyboard and Display Battery (GEB221)
• Keyboard: 34 keys (12 function keys, 12 alphanumeric keys), illumination Capacity: 4.4 Ah
• Memory card: CompactFlash cards (1GB)
• Number of data records: 1750 /MB Working temperature range: 0° C to +50° C
• Rainproof, 4 tripod stands, facilities for car mounting and water proof,
• Reflector-less capability – up to 500m
• Sensitivity: 6’ / 2mm Humidity: 95 %, non-condensing
• temperature range: 0° C to +70° C
