Two Stage R-C Coupled TransistorAmplifier

Experimental training board has been designed specifically for the study of two stage r-c coupled transistor amplifier. Practical experience on these boards carries great educative value for science and engineering students. Object: Study of the characteristics of two stage r-c coupled transistor amplifier :

• Study of the overload characteristics of the amplifier.
• Study of the frequency response of the individual as well as the cascade amplifier.
• Calculate the output and input impedance of the individual stages as well as that of cascade amplifier.

Features: The board consists of the following built in parts : 01. -12v d. C. Ic regulated power supply internally connected. 02. Two pnp transistors. 03. Adequate no. Of other electronic components. 04. Mains on/off switch, fuse and jewel light.
